TRUCK EXPLORER STANDARD

TRUCK EXPLORER STANDARD V6

Truck Explorer Standard kit consists of most popular functions for trucks. You could work by OBD or by direct connection to the ECU on the table over DirectConnect 2U tool.

Short description:

Includes licenses:

1 MB MEMO PLD (MR) external FLASH & EEPROMs Read&Write; Checksum; Chip-tuning protection remove.
2 MB KEYS Key programming on PLD (MR). MR&FR IMMO OFF
3 MB CALC Calculates codes for VeDoc (algorithm X1, X2, X8); FDOK (XT, XN) algorithms
4 FR FR&CPC Flash EEPROM Read/Write. OBD and DC2. CPC3 & CPC NAFTA not supported.
5 2011+ MEMO; KEYS; CALC; DC2 functionality with Continental PLD based on XC2xxx processor type. PLD firmware v.: 22B; 23E; 24B.
6 2014+ MEMO; KEYS; CALC; DC2 functionality with Continental PLD firmware v.: 23F; 24C; 25B, 26x
7 DC2 Operations by Direct Connection 2U tool.
DC2U hardware kit included
8 CRV S, ML, GL class CRV & CRV2 Flash&EEPROM R/W via OBD
9 CR (CDI) V-klass CR1 Flash & EEPROM R/W; WSP<>CR pairing
10 MCM BSL MCM1, MCM2, ACM1, ACM2- Flash & EEPROM Read / Write by DC2 in BSL mode
11 SFTP CALC MB SFTP (MP4) VeDoc/Fdok XS; XT; XN; X1; X2; X5; X8
12 SFTP DIAG MB SFTP (MP4) DTC Read /Erase. Full report. OBD/DC2
13 IVECO VCM IVECO VCM MEMO. FLASH EEPROM Read/Write OBD/DC2
14 MB EXTRA Speed limit R/W for PLD and FR; Torque limit R/W; AdBlue error Erase
15 CPC3 EXTRA Speed limit R/W for SFTP: MCM and CPC3;
16 ADM EXTRA Speed limit R/W for PLD and ADM;
17 MB DIAG Fault codes Read&Erase; All code descriptions are up to date
18 Android Truck Explorer Android 2.1 license
19 Update/support 12 months updates & support subscription

Includes hardware:

1 VEI V6 WiFi device
2 USB A to USB B
3 Micro USB-USB type A
4 OBD2F-4-MB14 (MB)
5 DirectConnect 2U tool with ISP port
6 PLD16 cable for DC2
7 DC2-ISP1 cable for BSL mode
8 DC2-OBD2-Power cable
9 DC2-FR+CPC cable
10 DC2 cable for MCM, MCM2, MCM2.1, ACM, ACM2.1
11 DC2-TransReader13 for transponder ID12, ID13

Support and updates for 12 months are included.

1. License MB MEMO
The license allows to Read/Write FLASH and EEPROMs of MR (PLD) control unit.
It is possible to connect to the unit via:
– OBD (MR is mounted inside truck) or
– direct connection with DirectConnect 2M tool (MR is placed on your table).

This function is especially useful for chiptuning works and recovering unit after the broken update. All operations are done via OBD, there is no need to decapsulate/open the unit, so unit stays in factory condition and therefore no warranty is voided.
This function allows cloning MR. You read one MR, save to *.bin file, and write it to another MR.

2. License MB KEYS
MB Keys learn – allows to add new keys for the truck over OBD (MR (PLD) control unit). No additional equipment is used, all operations are done offline, the only connection to the truck required.
It is possible to add new key, erase old keys, while connected to the unit via:
– OBD (MR is mounted inside truck) or
– direct connection with DirectConnect 2M tool (MR is placed on your table).
Disable immobilizer in FR and MR. IMMO OFF.

3. License MB CALC
MB VeDoc and FDOK calculators – calculates access codes for VeDoc (X1, X2, X8) and FDOK (XT, XN, XS) algorithms for MR (PLD) control unit.
Must be used together with XENTRY (DAS) software and compatible diagnostic tool where these codes are asked. All operations are done offline. Only connection to the truck required for VEDOC.
For FDOK calculations not needed connection to the truck. FDOK code for new and old DAS.
DAS password generator – calculates password asked by DAS to access some special functions (MR downgrade from Euro 4, 5 to Euro 3 etc. Disable AdBlue)

4. License FR
The license allows accessing FR memory. Supported FMR; FR; FR/CPC; CPC1EU; CPC2EU. Immo off in FR.
Not supported: CPC2 NAFTA; CPC2+ NAFTA; CPC4 NAFTA; CPC3; ADM2; ADM3.

5. License 2011+
For PLD memory read and write operation (category memo) PLD with XC2287 secured microprocessor. The license allows accessing firmware 22B, 23E, 24B from 2011 year.
Continental Euro5 PLD: (MCU XC2287 (flash 768kB), 1 EEPROM M95640).
Needed: MB MEMO license

6. License 2014+
For PLD memory read and write operation (category memo) PLD with XC2287 secured microprocessor.
The license allows accessing firmware 21x, 23F, 24C, 25x, 26x from 2011 year. Open access Read/Write memory for PLD, made on 2011 and later, with microprocessor Infineon XC2287.
Note: DirectConnect2M tool and License MB MEMO are required.
PLD must be opened. Manual will be provided by support team.

7. License DC2
The license allows work with DirectConnect 2U tool (DC2) for different vehicle control modules programming without complete vehicle system.
ISP helps Read & Write unknown or damaged firmware from vehicle control units. BSL mode, TriCore BL mode, Motorola BKG mode, NEC serial BL ready.
Read/write MR, MCMx, ACMx, CPC, FR, FFR, ADM. Learn a key for PLD, FFR, PTM. To have all options you need to have appropriative licenses.

8. License CRV
The license allows to Read/Write FLASH & EEPROMs of CRV1 & CRV2 engine control unit of Mercedes S, ML, GL class via OBD2.

9. License CR (CDI)
The license allows to Read/Write FLASH & EEPROMs of CDI engine control unit used in MB V-class, Sprinter and Vito via the diagnostic port. CDI<>WSP pairing.

10. License MCM BSL
A license for Read/Write Flash & exEEPROM of MCM, MCM2, ACM2 control units memory only over DirectConnect 2M tool in BSL mode.
Type 1. Continental MCM (MCU TC1796-256F / TriCore 1 EEPROM M95640) plastic.
Type 2. Continental MCM2 (MCU TC1796-256F / TriCore 1 EEPROM M95128) metallic
Type 4. Continental ACM2
Note: DirectConnect 2M tool is required. Full name of License is MB_MCMACM_BSL
Read procedure takes about 20 minutes.
Write procedure takes about 20 minutes.

11. License SFTP CALC
MB SFTP (MP4) VeDoc calculator (X1; X2; X8).
Calculator works by OBD or by DirectConnect 2M tool.
Important! License work only with appropriative MCM read/write license. You could calculate VeDoc only on MCM you could read/write. NOTE: SFTP – Strategic Future Truck Platform. Original name of MP4 EURO6 truck.

12. License SFTP DIAG
SFTP truck DTC Read/Erase. Full report in PDF format.
Diagnostic is available by OBD or by DirectConnect 2M tool.
License is merged with MB DIAG license.
NOTE: SFTP – Strategic Future Truck Platform. Original name of MP4 EURO6 truck.

13. License IVECO VCM
IVECO VCM FLASH & EEPROM memory Read/Write by OBD or by DirectConnect 2M tool connection.

14. License MB EXTRA
Speed limit R/W for PLD and FR
Torque limit R/W
AdBlue error Erase

15. License CPC3 EXTRA
Speed limit R/W for SFTP (MP4): MCM and CPC3;.

16. License ADM EXTRA
Speed limit R/W for PLD and ADM (KAMAZ).

17. License DIAG
The license allows to Read DTC with the error description on MP3 and SFTP (MP4) trucks.
Clear DTC.
Read and Erase fault codes. Export a full report to PDF file.

18. License Android
Truck Explorer Android 2.1 license. For phones (tablets) we created Android mobile app: “Truck Explorer” More simple, more useful. The license is included, but the software must be purchased in a Google Play store.

19. Update/support subscription.
Update/support subscription for 12 months is included in a kit. After 12 months device will work, but support and update would not be provided.
